X-ray Source Technology – X-Ray & Microfocus Sources

At the heart of the superior image quality of Nikon’s X-ray and CT systems are world-leading X-ray sources designed and manufactured in-house since 1986.

Product Highlights

Unique 225kV Rotating.Target 2.0

Rotating.Target 2.0 allows continuous operation up to 450W with up to 3 times higher resolution for the same power, or 3 times faster data collection for a given resolution.

Unique 450kV Microfocus Source

Nikon’s 450kV/450W microfocus X-ray source is the only one in the world to offer high energy combined with a high-resolution focal spot size of 80µm, allowing inspection of dense components.

3-x-ray-source-technology-160kv-nanotech-xi

Superior X-Ray Source

Nikon’s market-leading Xi Nanotech X-ray microfocus source is unique due to its exclusive integral generator design and unparalleled 160kV maximum energy and 20W true-target power.

Core Features

Unique X-ray Target Optimization

The unique multi-metal target allows users to change the X-ray emission profile for analysis of lower density materials. The target can be changed between tungsten, silver, molybdenum, and copper in seconds without breaking the vacuum.

Low Cost of Ownership

All Nikon's X-ray sources are open-tube design, which allows an unlimited lifecycle, with user-replaceable filament cups, offering a low cost of ownership.

One Source, 5 Target Options

Select the right target for your application: from the transmission target with sub-micron feature recognition, to the world's only Rotating.Target 2.0 for outstanding performance or the 320kV target for denser samples

Industries / Use Cases

Industries / Use Cases Paragraph

XT H Series

XT H 225 ST 2x

Automated CT

MCT225

XT V Series

Related Products

XT H Series

Nikon's versatile microfocus CT systems for high-resolution inspection of components, ranging from tiny plastic connectors up to aluminum castings for R&D, failure analysis and production quality control.

Discover the Product

Configurable Large Envelope X-ray and CT Systems

Nikon’s advanced, large envelope X-ray and CT systems provide ultimate versatility. They are configurable to inspect small and large parts in research, automotive, Li-ion battery manufacture and aerospace.

Discover the Product

AI Reconstruction

Nikon's AI Reconstruction revolutionizes computed tomography (CT) scanning through automated image enhancement powered by artificial intelligence (AI). Tailored to each customer's needs, it provides a new level of speed and quality to unlock superior defect detection while accelerating productivity.

Discover the Product
