Versatile Large-Envelope X-ray and CT Systems

Nikon’s versatile, large-envelope X-ray and CT systems can inspect items of diverse size and density, internally and externally, enabling them to perform virtually limitless tasks within industry, inspection bureaux and academia.

A multitude of configuration options to meet your exact inspection requirements

Next level X-ray CT

Nikon’s large-envelope system range combines metrology grade, granite-based manipulator construction with a large scanning volume, multi-source flexibility, dual detector functionality and an extensive range of CT acquisition modes, enabling them to excel in any inspection environment, from R&D labs to the shop floor.

Details of Nikon X-ray VOXLS 40 C 450

Product Highlights

Nikon X-ray VOXLS 40 C 450 - Highly configurable line-up

Highly Configurable Line-up

With 8 different X-ray sources, 7 detectors, 3 granite base lengths and 2 manipulator constructions to choose from, housed in either a single-piece cabinet, panelised room or pre-existing shielded enclosure, you’ll find a system configuration to match your requirements.

Nikon X-ray VOXLS 40 C 450 - Multi-source functionality

Multi-source Functionality

Select up to 3 X-ray sources from Nikon’s extensive microfocus range to ensure you have the optimum combination of penetrative power, resolution and scan speed for all your applications.

Nikon X-ray VOXLS 40 C 450 - Dual detector flexibility

Dual Detector Flexibility

A choice of industry-leading, flat panel detectors with small pixel sizes and fast exposures, combined with Nikon’s unique CLDA, enables high-throughput CT and DR for all part types, plus advanced scatter correction for high-density parts.

Nikon X-ray VOXLS 40 C 450 - Metrology grade manipulator

Metrology Grade Manipulator

Our granite-based manipulators are combined with rigid towers and precision motors and encoders. The resulting construction ensures superior mechanical and thermal stability, leading to enhanced positional accuracy and repeatability.

Nikon X-ray VOXLS 40 C 450 - Large scanning envelope

Large Scanning Envelope

With up to 4-position panel shift and synchronous Y-axis source and detector movement, the maximum available scanning envelope can accommodate samples up to 1000 mm swept diameter and over 1500 mm tall.

Nikon X-ray VOXLS 40 C 450 - Automation-ready for the shop floor

Automation-ready for the Shop Floor

When combined with an integrated robotic loader and the Nikon Automation OPC UA Interface, our large envelope systems are automation ready for closed-loop inspection at high speed in a Quality 4.0 production line environment.

Industrial Applications

Nikon Large Envelope CT Range at a glance

For ease of installation and relocation, the VOXLS 40 C 450 and M2 models are available in a single-piece cabinet enclosure as standard, whereas the ultra-large format C2 and C3 are housed in a modular panelised room. Alternatively, all systems can be offered as manipulator-only configurations for a pre-existing enclosure.

VOXLS 40 C 450

Up to Dual Sources + Dual Detectors
Synchronous-Style Manipulator
Standard Scan Vol:
800 mm (Ø) × 1415 mm (H)
275 kg Max Payload

VOXLS 40 C 450
Nikon X-ray VOXLS 40 C 450 - Detail

M2

Up to Triple Sources + Dual Detectors
Bridge-Style Manipulator
Standard Scan Vol:
630 mm (Ø) × 988 mm (H)
180 kg Max Payload

M2
Nikon X-ray VOXLS 40 C 450 - Detail

C2

Up to Triple Sources + Dual Detectors
Synchronous-Style Manipulator
Standard Scan Vol:
1090 mm (Ø) × 1285 mm (H)
275 kg Max Payload

C2
Nikon X-ray VOXLS 40 C 450 - Detail

C3

Up to Triple Sources + Dual Detectors
Synchronous-Style Manipulator
Standard Scan Vol:
1090 mm (Ø) × 2460 mm (H)
400 kg Max Payload

C3

Core features

VOXLS 40 C 450 brochure cover

VOXLS 40 C 450

Configurable x-ray-cover

Configurable X-ray CT systems
