Mikroskop yang diperbarui ini akan memperkuat rangkaian solusi mikroskopi industri yang komprehensif, dengan mengadopsi sumber cahaya LED dengan rendering warna tinggi.
Desain inovatif Nikon memungkinkan teknik pencitraan yang jernih, meliputi kontras tinggi, bidang terang, bidang gelap, polarisasi (POL), kontras interferensi diferensial (DIC), dan kontras optik interferometri sinar ganda.
Setiap kamera Nikon Digital Sight secara efisien dapat mengambil gambar sampel dan mengirimkannya ke perangkat lunak pemrosesan gambar dari rangkaian NIS-Elements, disertai dengan data mikroskop mengenai lensa objektif yang digunakan, pengaturan pembesaran dan intensitas cahaya.
Cahaya terpantul: bidang terang, bidang gelap, polarisasi (POL), kontras interferensi diferensial (DIC), epi-fluoresensi, dan interferometri dua berkas.
Cahaya ditransmisikan: bidang terang, bidang gelap, polarisasi (POL), kontras interferensi diferensial (DIC), dan kontras fase.
Dari lamphouse hingga eyepiece, komponen bisa dipilih agar sesuai pemakaian pengguna. Komponen tersebut meliputi stand, stage, objektif, nosepiece, kepala optik, eyepiece, kamera digital, filter dan aksesori teknik kontras.
LV100NDA LED mampu mendeteksi dan mengontrol nilai lensa objektif, posisi, intensitas cahaya, apertur dan kontras melalui perangkat lunak Nikon.
Sedangkan LV100ND LED mampu mendeteksi dan melaporkan lensa objektif yang digunakan oleh LV-NU5I dan LV-INAD.
Pemosisian kontrol operator yang optimal dan eye-tube dengan sudut variabel memungkinkan pekerjaan bebas lelah, menghasilkan gambar tepat dan di posisi tepat untuk mengamati bahan, semikonduktor, dan komponen industri dengan benar.
Epi-illuminator dengan sumber cahaya LED dan halogen tersedia untuk pencitraan universal dan fungsi motorisasi.
Epi-illuminator bermotor LV-UEPI2A cocok untuk berbagai metode kontras, yang secara otomatis mempertahankan kondisi pencitraan optik ketika mengubah dari epi-bidang terang ke bidang gelap.
LV100ND LED | LV100NDA LED | |
Base unit | Maximum sample height: 38 mm (when used with LV-NU5 U5 nosepiece and LV-S32 3x2 stage / LV-S64 6x4 stage) 12V50W internal power source for dimmer, coarse and fine adjustment knobs Left: coarse and fine adjustment / Right: fine adjustment, 40 mm stroke Coarse adjustment: 14 mm/turn (with torque adjustment, refocusing mechanism) Fine adjustment: 0.1 mm/turn (1 µm/graduation) | Maximum sample height: 33 mm (when used with LVNU5AI U5AI nosepiece and LV-S32 3x2 stage / LV-S64 6x4 stage) 12V50W internal power source for dimmer, coarse and fine adjustment knobs Left: coarse and fine adjustment / Right: fine adjustment, 40 mm stroke Coarse adjustment: 14 mm/turn (with torque adjustment, refocusing mechanism) Fine adjustment: 0.1 mm/turn (1 µm/graduation) |
Nosepieces | C-N6 ESD Sextuple Nosepiece ESD, LV-NU5 Universal Quintuple Nosepiece ESD LV-NBD5 BD Quintuple Nosepiece ESD, LV-NU5I Intelligent Universal Quintuple Nosepiece ESD D-ND6 Sextuple DIC Nosepiece | LV-NU5AI Motorized Universal Quintuple Nosepiece (High-durability motorized 5-hole universal nosepiece) |
Episcopic Illuminators | LV-UEPI-N High color-rendering LED Lamphouse C-LL-I: 50,000 hours of life *1 Bright/darkfield switch and linked aperture stop (centerable), field diaphragm (centerable), accepts ø 25 mm filter (LV-C-LCB), polarizer/analyzer; equipped with noise terminator LV-UEPI2 High color-rendering LED Lamphouse C-LL-I: 50,000 hours of life *1 Fluorescence LED light source D-LEDI (with light adjustment (PC controllable)) *option Bright/darkfield switch and linked aperture stop (centerable), field diaphragm (centerable), automated optical element switching feature matched to brightfield, darkfield, and epi-fluorescence switch Accepts ø 25 mm filter (LV-C-LCB), polarizer/analyzer, λ plate, excitation light balancer; equipped with noise terminator | LV-UEPI2A High color-rendering LED Lamphouse C-LL-I: 50,000 hours of life *1 Fluorescence LED light source D-LEDI (with light adjustment (PC controllable)) *option Motorized operation and control of illumination selector turret Motorized aperture stop linked to bright/darkfield selector (automatic optimization matched to objective lens), field diaphragm (centerable) Accepts ø 25 mm filter (LV-C-LCB), polarizer/analyzer, λ plate, excitation light balancer; equipped with noise terminator |
Diascopic Illuminator | Built-in high color-rendering LED Lamphouse C-LL-I (50,000 hours of life) (Fly Eye optical system) *1 Internal aperture, field diaphragm, filter (45C-LCB); transmitted/reflected selector switch |
|
Eyepiece tubes | LV-TI3 trinocular eyepiece tube ESD (Erected image, FOV: 22/25), LV-TT2 TT2 tilting trinocular eyepiece tube (Erected image, FOV: 22/25), P-TB Binocular Tube (Inverted image, FOV: 22), P-TT2 Trinocular Tube (Inverted image, FOV: 22) | |
Stages | LV-S32 3x2 stage (Stroke: 75 x 50 mm with glass plate) / LV-S32SGH slide glass holder LV-S64 6x4 stage (Stroke: 150 x 100 mm with glass plate), LV-SRP P revolving stage NIU-CSRR2 Ni-U right handle rotatable ceramic stage (Stroke: 78 x 54 mm), C-CSR2S right handle stage (Stroke: 78 x 54 mm: Used with stage adapter LV-SAD) |
|
Condensers | LWD achromat condenser (brightfield), LV-CUD U condenser dry (phase contrast, diascopic DIC, darkfield), Achromat 2x-100x slide condenser (brightfield), DF dry condenser (darkfield), and others | |
Eyepieces | CFI eyepiece series | |
Objective lenses | Industrial Microscope CFI60-2/CFI60 optical system Objective lens series: Combinations in accordance with the observation method | |
ESD performance | 1,000 to 10V, within 0.2 sec. (excluding certain accessories) | |
Power consumption | 0.7 A / 58 W *2 | 0.7 A / 58 W *2 |
Weight | Approx. 9 kg | Approx. 10 kg |
*1: Estimated value based on Nikon regulations.
*2: Reference value based on Nikon regulations.
