LC15Dx

The LC15Dx captures the smallest of details with highest accuracy providing valuable insights for components ranging from small airfoil blades to intricate sheet metal parts.
  1. Home
  2. Products
  3. 3D Laser Scanners
  4. Automated 3D Scanning
  5. LC15Dx

Measurements at the Highest Accuracy Level

Thanks to custom-designed, top quality Nikon optics, the LC15Dx captures the smallest details with very high precision while maintaining speed and data quality. It does this by optimising the laser settings in real time to match the type and reflectivity of the material being inspected.

Product Highlights

Precision and Detail

With its class-leading optics, the LC15Dx accurately captures the smallest details on a wide variety of high precision parts.

Zero Warm-Up

Thermal compensation eliminates the need to wait for the scanner to warm up, allowing accurate measurements right from the start.

Multi-Sensor CMM

In combination with a tactile probe, the LC15Dx creates a versatile, multi-sensor CMM, with fully automatic sensor exchange using an optional probe change rack.

Core Features

Focus

LC15Dx

Probing Error (MPEp)11.9 µm (0.000075”)
Ball Bar Length (MPEE)24µm +L/350mm
(0.00016 +L/13.78“)
Multi-Stylus Test (MPEAL)33.9 µm (0.00015“)
ISO Probing Form Error47 µm (0.00027“)
ISO Probing Size Error all515 µm (0.000591”)
ISO Probing Dispersion Value67,6 µm (0.000299“)
ISO Cone Angle7100°
Scanning Speed (approx)70,000 points/sec
Resolution (point spacing)22 µm (0.00087“)
Points Per Line(approx.) 900
Measuring Temperature Range18-22°C (64.4-71.6° F)
Operating Temperature Range10-40°C (50-104° F)
Weight370 g (0.82 lbs)
Ingress ProtectionIP30
Laser SafetyClass 2
Enhanced Scanner PerformanceESP3
Daylight FilterYes
Probe Head Compatibility PH10M, PH10MQ, CW43, PHS

All accuracy specifications valid for a CMM with an accuracy of 2µm + L/350 or better using manufacturer supplied test sphere.
1 Nikon Metrology test comparable to EN/ISO 10360-2 MPEP using 1ơ sphere fit.
2 Nikon Metrology test comparable to EN/ISO 10360-2 MPEE
3 Nikon Metrology test comparable to EN/ISO 10360-5 MPEAL

Accuracy specifications according ISO 10360-8:2013:
4 PForm.Sph.1×25:Tr:ODS,MPE : Maximum probing form error using 25 representative points in translatory scanning mode
5 PSize.Sph.All:Tr:ODS,MPE : Maximum probing size error All using all measured points in translatory scanning mode
6 PForm.Sph.D95%:Tr:ODS,MPL : Maximum probing dispersion value using 95% of the measured points in translatory scanning mode
7 Cone angle : Region of sphere on which the measured points are selected
