Non-Electronics Applications for XT V Series

With sub-micron feature recognition, the XT V 160 X-ray and CT system is applicable to a wide range of industries, not only electronics but also medical, automotive, aerospace, consumer products and much more.

Product Highlights

Superior X-ray Source

Nikon’s market-leading Xi Nanotech X-ray microfocus source is unique due to its exclusive integral generator design and unparalleled 160kV maximum energy and 20W true-target power.

Increased Productivity

The equipment offers a best-in-class inspection area to footprint ratio, accommodates samples up to 711mm x 762mm (28”x30″) and has a large detector field-of-view (up to 25cmx20cm).

Cost Effective 3D CT

3D inspection with CT and X.Tract provides digital slicing in any orientation for full 3D component NDT, providing a high accuracy, cost-effective CT solution for smaller components.

Core Features

Collision-free

Truly collision-free sample manipulation with an intelligent, 5-axis programmable stage and intuitive joystick control (alongside click-and-point software control) minimises training times and streamlines the user experience.

AdobeStock_319685939_Quality engineer measuring some moldings by professional 3D measuring system machine, industrial concept

Automated Inspection Programs

Maximise productivity with automated inspection programs utilising HTML reporting that is readable on any PC. Programs are built using an intuitive drag-and-drop interface, with pass/fail optimisation, visual checks and other actions possible within the program.

Industry-Leading Image Quality

The combination of our industry-leading, large area flat panel detector with small pixel sizes and fast exposures with our small focal spot size microfocus X-ray source, results in high-quality and high-resolution imaging.

Low Cost of Ownership

The open-tube X-ray source allows a virtually unlimited lifecycle, with user-replaceable filament cups that simply click into place. The unique, integrated generator design requires no high-voltage cable maintenance, offering low cost of ownership.

AdobeStock_319418602 (1) Precision sensors for fast, accurate acquisition of component dimensions and surface data. Measurement systems for CMMs

Industries

Industries / Use Cases Paragraph

XT V Series

Download


XT V130C Cost-effective 130kV system for inspection of electronic components	XT V160 Premium 160kV system for high accuracy X-ray and CT applications
Power	Power
Resolution	Resolution
Field of View	Field of View
CT Ready	CT Ready
X.Tract Ready	X.Tract Ready

Related Products

XT V 130 and XT V 160

Nikon’s XT V range comprises world-class X-ray and CT systems for non-destructive inspection of electronic components (PCBs, BGAs, chips and much more).

Discover the Product

Speak To Us About This Product

If you would like further details on this product or a more in-depth description, our expert team will provide you with additional information and, if required, arrange an on-site visit.

Talk to us in detail about your project and our experts will advise you on the best inspection system to meet your requirements.

Please fill out the form opposite and we will get in touch with you shortly.
